3.5m³ Self Loading Concrete Mixer Series (Standard / Custom / Rotation)

3.5m³ Concrete Mixer Series: 116hp Power, Three Specialized Configurations, and Unmatched Versatility

Overview

The 3.5m³ Self Loading Concrete Mixer Series gives a complete answer to the changing needs of construction with its variety of features. The series comes with three different models that are all based on the same powerful platform: the JBC(5500) Standard that is the most efficient, the LZ(3500) Customized that is for the strongest, and the JBC(5500) Synchronous Rotation that is for the simultaneous unloading in all directions.

All models run on a YD4J22G diesel engine that generates 85 kW (116 hp) and 390 Nm of torque. The machines boast a 5500-liter geometric drum, which can produce 3.5 cubic meters of concrete in a single mix. In any 4×4 mobility situation, whether you are working with regular road maintenance, huge loads, or side discharge areas that are hard to reach, this concrete mixer series will provide exactly the capability you need.

Three Specialized Model Configurations

• JBC(5500) Standard: This is the most balanced version with an operational weight of 8300 kg.
• LZ(3500) Customized: The machine is built with a reinforced chassis structure for heavy-duty work, which leads to the rise of operating weight to 8800 kg.
• JBC(5500) Rotation: The machine features a synchronous slewing drum that allows unloading from any direction, the total weight being 8500 kg.

Key Features

• Powerful Diesel Powertrain: Driven by the YD4J22G Turbo Diesel Engine (85 kW / 116 hp @ 2400 rpm). A torque converter and an open hydraulic gear pump are used in the transmission system allowing the models to reach the maximum speed of 36 km/h.
• Optimized Drum & Mixing Performance: The double cone drum having 5500L capacity includes a double spiral agitating screw and a convex bottom. At a speed of 16 rev/min, the drum guarantees proper concrete mixing, which is especially designed for an output of 3.5m³.
• Heavy-Duty Axles & Tires: The series employs robust special bridges along with planetary reduction gears.
• Standard & Custom Models: Equipped with 16-70-20PR tires.
• Rotation Model: Enhanced with 122R22.5 tires to carry the slewing mechanism and load distribution.
• Excellent off-road traction: All models are equipped with a rear axle that can swing ± 28° for excellent off-road traction.
• Operator Comfort & Control: The cabin is sealed with a front window that can be tilted, a suspension seat that can be adjusted, and a heating/cooling system that is integrated. Water management for each mix is accurately done by a “Self-suction” 24V water pump with a quantitative controller.

Parameter Description

Technical Specifications Comparison

General Specifications(Standard)
